• Engine Brand: Kohler®
• Engine Model: 7000 Series
• Engine Model Number: KT735
• Engine Displacement: 725cc
• Engine Output: 24HP
• Starter Type: Electric
• Fuel Tank Capacity: 3.5 gal. US (13.25 L)
• Cylinders: Twin
• Engine Start: Ignition Key
• Engine Oil Capacity: 2.0 qt. US (1.89 L)
• Lubrication: Fully pressurized
• Charging System: 12 amp regulated
• Fuel Gauge: No
• Governor: Mechanical
• Choke: Choke-a-matic
• Air Filter: Dual element
• Oil Filter: Yes
• Fuel Delivery: Carburetor

• Battery: 210 CCA
• Battery Type: AGM (Absorbent Glass Mat)
• Battery Voltage: 12V

• Transmission: Hydro-Gear EZT 2200
• Forward Speed: 7 MPH / 11.3 km/h
• Reverse Speed: 3.5 MPH / 5.6 km/h
• Drive System: Hydrostatic

• Deck Cutting Width: 54 in
• Deck Wash: No
• Deck Material: 11-gauge steel
• Deck Engagement (PTO): Electric
• Deck Construction: Fabricated
• Blade(s): 3
• Deck Lift: Foot pedal with Dial Adjust
• Cutting Height Range: 1” – 4.5”
• Anti-Scalping: 3 gauge wheels
• Deck Positions: 15

• Warranty: 3-year unlimited hours
• Frame Warranty: Lifetime Limited
• Deck Shell Warranty: Lifetime limited
• Commercial Warranty: No

• Frame: 2” x 2” tubular steel
• Turning Radius: 0°
• ROPS: No
• Rear Tow Hitch: Yes
• Corrosion Protection: Yes

• Cruise Control: No
• Brakes: Disc
• Steering Control: Lap Bars

• Seat Type: 20″ high back
• Armrests: No
• Seat Adjustment: Knob

• Rear Tires: 20”x 10”- 8”
• Front Tires: 11″x 6″-5″
• Tire Tread: Turf Master / Multi Trac

• Hour Meter: No
• Mulch Kit: Available separately
• Headlight(s): Dual-LED
• Cup Holder: Yes
• Operator Presence System: Yes
• Parking Brake: Lap Bar Integrated
• Model Number: 17AREACM010

• Series: Ultima Series™ ZT
